Rated battery voltage

12VDC

24VDC

48VDC

48VDC

48VDC

Inverter output

Rated power

1200W

3600W

6200W

8200W

10200W

Peak power

2400W

7200W

12400W

16400W

20400W

Waveform

Pure Sine Wave

AC voltage(Battery mode)

(220vac~240vac)±5%230vac(Default)

Inverter efficiency(Max)

93%

94%

Transfer time

10ms(UPS、VDE4105);20ms(APL)

No load power consumption

<30W@12VDC

<30W@24VDC

<40W@48VDC

<75W@48VDC

ACinput

Voltage

230VAC

Selectable voltage range

170~280VAC(UPS)90~280VAC(APL)

Frequency range

50Hz/60Hz(Auto sensing)

Battery

Battery voltage

12VDC

24VDC

48VDC

Floating charging voltage

13.5VDC

27VDC

54VDC

Overcharge protection voltage

14.6VDC

29.2VDC

58.4VDC

Solar charger

&AC charger

Solar charger type

MPPT

MPPT Maximum PVArray power

2000W

4000W

6000W

8000W

10000W

MPPT output voltage range

60-400V

60-450V

60-450V

60-450V

Maximum PVarray open circuit voltage

450V

500V

500V

500V

Maximum Solarcharge current

60A

80A

80A

150A

Maximum AC charge current

60A

80A

80A

120A

Maximum charge current

60A

80A

80A

150A

Physical

Machine size(W*D*H)(mm)

261*99*354

309*109*334

309*109*440

390*138*500

Package size(W*D*H)(mm)

472*345*180

452*395*190

558*395*190

620*492*263

Net weight(kg)

5.7

8.3

9.6

18

Gross weight(kg)

6.7

9.3

10.6

19

Environment

Humidity

5%to 95%Relative humidity(Non-condensing)

Operating temperature

0℃~55℃

Storage temperature

-15℃~60℃
