Basic parameters:
Core material: Lithium iron phosphate
Series parallel mode (S series, P parallel): 16S1P
Nominal voltage:48V/51.2V
Nominal capacity: 400Ah
Size (mm): 584*360*758mm
Weight: 184kg
Color: optional
Parallel support: supports parallel wiring terminals
Output port method: wiring terminal
Charging method: CC/CP/VP
Charging current: 0.2C (standard)
Maximum charging current: maximum 0.5C @ 25 ℃
Charging cutoff voltage: 58.4V/CELL
Discharge method: CC/CP/VP
Discharge current: 0.5C
Maximum discharge current: maximum 0.6C @ 25 ℃
Discharge cutoff voltage: 44.8V
Communication interface: RS485/RS232/CAN
Charging working temperature: Charging: 0~+50 ℃
Discharge working temperature: Discharge: -20~+55 ℃
Warranty period: 36 months
