Basic parameters:
Core material: Lithium iron phosphate
Series parallel mode (S series, P parallel): 4S2P
Nominal voltage: 12.8V
Nominal capacity: 100Ah
Size (mm): 412 * 326 * 137mm
Weight: 21kg
Output port method: wiring terminal
Charging method: CC/CV
Charging current: 0.2C (standard)
Maximum charging current: maximum 1C @ 25 °
Charging cutoff voltage: 14.6V
Discharge method: CC
Discharge current: 0.5C
Maximum discharge current: maximum 1C @ 25 °
Discharge cutoff voltage: 11.2V
Display: LCD
Charging working temperature: charging 0~+50 ℃
Discharge working temperature: discharge -20~+55 ℃
Warranty period: 36 months
